Online UPS

Showing all 4 results

•

  Range	5KVA to 600KVA
  Phase	1-1, 3-1, 3-3 Phase (Input/Output)
  Display	32 bit DSP based design
  Mode	Multi modes working SBG/SGB/Export/Batteryless
  Input	IGBT with PF >0.9 With IGBT rectifier upto unity With SCR upto 0.8 With APFC upto 0.95
  Interactive	Interactive front LCD to do all settings via display
  Control	MODBUS control for handshaking
  Redundancy	Paralleling option/Hot Standby with bypass
  Monitoring	Remote monitoring using GSM/RS-485

  Online UPS

  Industrial UPS: HTXi

  Read more
•

  Range	1KVA to 10KVA
  Phase	1-1 Phase
  Optional Features	Parallel Port / USB / Temperature Detection
  Efficiency	95% (up to 98% in ECO Mode)
  Input Power Factor	0.99
  Parallel Technology	Advanced Digital Parallel Technology
  50 / 60 Hz frequency	Yes, Auto Sensing
  Communications	RS232 (Standard), USB / RS485 / Dry contacts / SNMP / Battery Temperature Compensation (optional)
  Transfer time	Mains Mode to Battery Mode: 0 ms.
  Total harmonic distortion (THDv)	1% (linear load), 5% (non-linear load)

  Online UPS

  Online UPS 1Ph-1Ph: ETXi

  Read more
•

  Range	10KVA to 80KVA
  Phase	3-1 Phase
  Type	SCR / PFC / IGBT Rectifier
  Input Power Factor	PF >0.99
  Parallel Technology	Advanced Digital Parallel Technology
  Interactive	Interactive front LCD to do all settings via display
  Control	MODBUS control for handshaking
  Transfer Time	Mains Mode to Battery Mode: 0 ms.
  Monitoring	Remote monitoring using GSM/RS-485

  Online UPS

  Online UPS 3Ph-1Ph: ETXi

  Read more
•

  Range	5kVA to 600kVA
  Phase	3-3 Phase Output
  Display	32 bit DSP Based Design
  Type	Standalone UPS / Hot Standby UPS / N+1 or 1+1 Parallel Redundant UPS
  Power Factor	Factor IGBT Rectifier with PF >0.9
  Design	Customized Robust Design
  Interactive	Interactive Front LCD to do all Settings via Display
  BMS Compatibility	Integration with Battery Management Systems (BMS)
  Cold Start Capability	Yes, Allows the UPS to Initiate and Supply Power using only Battery Reserves
  Monitoring	Remote monitoring using GSM/RS-485

  Online UPS

  Online UPS 3Ph-3Ph: HTXi

  Read more
