| Key Info | |
|---|---|
|
Range |
1KVA to 10KVA |
|
Phase |
1-1 Phase |
|
Optional Features |
Parallel Port / USB / Temperature Detection |
|
Efficiency |
95% (up to 98% in ECO Mode) |
|
Input Power Factor |
0.99 |
|
Parallel Technology |
Advanced Digital Parallel Technology |
|
50 / 60 Hz frequency |
Yes, Auto Sensing |
|
Communications |
RS232 (Standard), USB / RS485 / Dry contacts / SNMP / Battery Temperature Compensation (optional) |
|
Transfer time |
Mains Mode to Battery Mode: 0 ms. |
|
Total harmonic distortion
(THDv) |
1% (linear load), 5% (non-linear load) |
1KVA to 10KVA
1-1 Phase
0.99
Efficiency
95% (up to 98%)
Parallel Port, USB,
Temp Detection
Advanced Digital Parallel
Tech
RS232 (Std), USB, RS485, SNMP, BTC
1% (linear),
5% (non-linear)
EnerTech is a leading brand of UPS manufacturers in India and one of the best online UPS suppliers. EnerTech offers a wide range of Online UPS from 1KVA to 10KVA based on the latest technology, built to withstand harsh environmental conditions and unstable power scenarios—perfect for everything from small offices to mission-critical applications.
Our range of ETXi Online UPS consists of new generation microprocessor-based high-frequency double conversion technology, providing continuous power without interruptions.
This system combines advanced DSP (Digital Signal Processing) with three-level architecture, ensuring efficient power management and minimal energy loss—up to 95% efficiency, rising to 98% in eco mode. The built-in Active Power Factor Correction (APFC) optimizes power usage, reaching a power factor of 0.99.
With an output power factor of 0.9, the UPS delivers stable and robust energy to critical applications. Thanks to EnerTech’s digital parallel technology, it supports seamless scalability and redundancy.
It features a wide input voltage range of 140–300 VAC with 50/60 Hz auto-sensing, making it compatible with various power sources. The cold start capability ensures the UPS can operate even without mains power.
Optimized for cooling, the system includes rear ventilation and a variable-speed fan for temperature control. Built-in software and hardware protection features guard against electrical issues to ensure uninterrupted performance.
Fast battery recovery recharges up to 90% capacity within 3 hours. Smart battery features like automatic floating/equalizing control and charger dormancy extend battery life by up to 50%, enhancing overall system reliability and lifespan.
| Input | |
|---|---|
| DC Voltage | 140 – 280 V |
| Input Frequency | 50 / 60 Hz (auto-sensing) |
| Input Power Factor | >=0.99 |
| Output Voltage | |
| Nominal Output Voltage | 208 / 220 / 230 / 240 Vac (settable via LCD) |
| Waveform | Sinewave |
| Frequency | 45 ~ 55 Hz or 55 ~ 65 Hz (synchronized); 50 / 60 Hz ± 0.1 Hz (battery mode) |
| THD | <=1% (linear load), <=5% (non-linear load) |
| Crest Factor | 3:1 |
| Inverter Technology | Double conversion, Microprocessor based IGBT, PWM Technology |
| Overload Capacity | 105% ~ 125% for 1 min, 125% ~ 150% for 30s, >150% for 300 ms |
| Change Over Time | 0 sec |
| Battery | |
| Nominal Battery Voltage VDC | 96 / 120 / 180 / 192 V |
| Type | Sealed Maintenance Free (SMF-VRLA) / Lead Acid -Tubular |
| Protection | DC over, DC under, Short Circuit, Overload, AC under, AC over |
| Indication | |
| LCD & LED | Mains ON, UPS ON, Battery %, Load %, AC/DC under/over, Overload |
| Metering | Input V, Output V, Input Frequency, DC V, Batt I, Input I, Output I |
| General | |
| Efficiency | > 90% to 98% in ECO mode |
| Noise (above ambient) | < 50 db at 1 mtr |
| Cooling | Forced Air Cooling |
| Communication | RS232 (standard), USB / RS485 / dry contacts / SNMP / battery temp. compensation (optional) |
| Transfer Time | Mains mode to battery: 0 ms; Inverter to bypass: 4 ms (typical) |
| Protections | Short-circuit, overload, overtemperature, battery discharge, fan test |
| Display | LCD + LED |
| Standards | |
| EN 62040-1, EN 62040-2, EN 61000-3-2, EN 61000-3-3, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, IEC 61000-2-2, IEC 62040-2, IEC 62040-1, IEC 62040-3 | |
| Environment | |
| Operating Temperature | 0°C ~ 45°C |
| Storage Temperature | -25°C ~ 55°C (without batteries) |
